XWZXJ Automatic packing machine

Our company has been producing and manufacturing food machinery products for many years, the main products are: chain conveyor, belt conveyor, mesh belt conveyor, elevator, spray cooling, sterilization equipment, bottle washing machine, air dryer, can sealing machine, cage loading and unloading equipment, palletizing and depalletizing machine, semi-automatic carton boxing machine, case sealing machine, etc. This automatic cartoning machine is a highly integrated and fully automatic equipment, integrating three functions of carton opening machine, carton packing machine and carton sealing machine, which can automatically complete carton opening, can packing, tape sealing and other actions, improving the efficiency of cartoning and reducing the labor intensity of workers. And according to the needs of customers to choose 16 cans / box, 20 cans / box or 24 cans / box work mode, to achieve the diversified needs of users packing, better reflect the characteristics of the equipment fully automatic, multi-functional. This equipment adopts vacuum suction cup pull-down type to open the box, side push type to box, both sides of the side seal type to seal the box, compact and reasonable structure layout, stable and efficient work. The equipment is equipped with PLC programmable controller and display screen, which is more intuitive and convenient to operate.

Functional characteristics

Equipment composition material.

Name

Description

Inlet box drive system

Servo motor, pitch shift, CNC positioning control, signal detection.

Inlet tank drive system

Speed reducing motor, frequency conversion speed control.

Electrical control system

Programmable controller (PLC) centralized control, touch screen operation.

Pneumatic control system

Pneumatic cylinder and solenoid valve, PLC centralized control.

Into the tank to separate the way

Isometric disaggregation plate, tank in place, missing tank, full tank signal detection

Open box molding method

Signal detection, cylinder action, vacuum suction, mechanical limit opening.

Into the box way

Pitch shift, box page folding.

Into the box action mode

Guiding and cylinder pushing.

Front box page folding method

Complete box entry, pitch shift, front box page folding

Sealing method

Adhesive tape bonding, bilateral tape gluer sealing during pitch shift.

Operation method

Start button or touch screen touch button start.

Body Material

Stainless steel 304 (supplemented with aluminum parts)

PLC, inverter, human-machine interface, and other electrical components are adopted from domestic famous brands.

Main Technical Parameters

Use voltage

AC220V 50Hz

Whole machine power

3.5K W

Use of air pressure

≥0.5~0.6MPa

Gas consumption

0.5㎥/min

Packing capacity

12~15 boxes minutes ≥720 pieces/hour

Applicable bottle type

Φ50~100mm(Made to sample)

Applicable bottle height

H50~150mm(Made to sample)

Package specification

On-demand

Overall machine size (including non-powered roller belt)

L74580mm  W2800mm  H1600mm
