XWZX400A Semi-automatic basket loading and unloading unit

Product overview

After sealing, the tin can (can-pull beverage) is transported into the loading platform through the conveying system. After the platforms are arranged in rows, it is pushed to the bottom plate of the sterilizing basket which can be movable on the top of the hydraulic elevator. After filling one layer, the hydraulic elevator drops to a certain height (the tank is raised with the cushion plate), puts the cushion plate on it, and pushes a row of cans in from the loading platform, so as to circulate until it reaches the end. Fill the whole sterilizing basket. The sterilizing cross track car, which is sent directly to the sterilizing pot. After sterilization, the sterilization basket is also pulled from the car to the straight track of the unloading basket, and then into the unloading basket area. The next unloading action is opposite to the loading action. After discharging the sterilizing basket of canned food, it exits and enters the loading basket area through rotary device and bridge.
(This machine can be customized according to customer needs to achieve fully automatic operation.)

Functional characteristics

Main Technical Parameters

Model

XWZX400A

Production capacity

100 ~ 400 cans/min

Power

3KW

Weight

1500kg

Dimension

5000×8000×1300mm



XWZX400A Semi-automatic basket loading and unloading unit

Marvelous Design Meets Rigorous Manufacturing

15

Years Of Experience

Zhejiang Newway Food Machinery Co., Ltd is Custom XWZX400A Semi-automatic basket loading and unloading unit manufacturers and OEM XWZX400A Semi-automatic basket loading and unloading units suppliers, The company is mainly engaged in the design and manufacture of beverages, canning machines and sealing machines packed with tinplate, aluminium, plastic and paper materials, as well as related products. Undertake the whole production line of easy-to-open beverage (including steam, nonsteam), sauce filling and sealing production line, Babao porridge canning, food, fruit and vegetable canning production line, etc. The company fully uses CAD and CAM to design products. It is in a leading position in the field of filling and sealing equipment for canned food and beverage in China. The company specializes in the production of high-speed canning filling and sealing units and production lines, which make due contributions to the localization of similar imported equipment, reduce investment costs in the food and beverage industry, improve labor productivity of enterprises, and promote the rapid development and growth of the industry. The company relies on strong technical force and effective technical guarantee, flexible business philosophy and quality service, Favourable manufacturing technology, excellence in product quality and good reputation, to serve the vast number of new and old customers, and wholeheartedly welcomes friends from all walks of life to visit and patronize.
  • 2019

    Established in

  • 6,000m2

    plant area

  • 80

    Employees

  • 10 +

    Patents

Focus on the field of canned packaging and serve the domestic food industry.

Newway aims to be the partner of choice for its customers, providing more efficient food packaging solutions, high technology, expertise, flexibility and fast service.

  • Pragmatic

    People-oriented, customer-oriented, realistic, down-to-earth. In the market competition to seek the appropriate path of enterprise development and project development, to create value with products and services, to enhance the company's market competitiveness.

  • Innovation

    The society is developing day by day, and we are brave to stand on the tide and dare to be the first. Innovation is the soul of the enterprise, and only through innovation can we maintain the vitality of the enterprise.

  • Cooperation

    Standardize management, operate in good faith, follow the law and give back to the society. Establish a sound corporate governance structure, operation mechanism and business process, uphold the spirit of professionalism and dedication, and earnestly fulfill the social responsibility of a corporate citizen and win the affirmation of the market.

  • Our goal

    Our ambition is ambitious, our goal is clear and never-ending. Our goal is the spiritual driving force for our company to win competitiveness.

Company Certificate

Continuously strengthen the research and development and innovation of core technologies, keep improving, and ensure the excellent performance of each product with Favourable production equipment, strict quality management, and precise testing procedures.

Plant Equipment

As OEM XWZX400A Semi-automatic basket loading and unloading unit manufacturers, the company has many of cutting-edge automated
production lines in China.

  • Factory

  • Factory

  • Factory

  • Factory

  • Factory

  • Factory

  • Factory

  • Factory

Related Products

LATEST NEWS

FAQ

  • How to debug the can filling production line?

    Everyone should understand these relevant knowledge in the production operation of the can filling production line, and customers should operate in accordance with the rules and regulations when using and operating, so as to ensure the production and protection of machinery and equipment while greatly improving work efficiency, so as to achieve production and processing benefits . In recent years, due to its high working power, the can filling production line has been widely used in major construction sites, and has also achieved good benefits and guarantees. But do we understand that we need to debug the can filling production line before use to see if it can work normally, so let's learn how to debug the can filling production line first? The can filling production line is attributed to a change in the zigzag structure of the steel bar. The can filling production line should be installed on a flat and solid ground. When the load-bearing frame is installed, the base of the load-bearing frame should be aligned with the base line of the guide cylinder, the straightening cylinder, the lower cutter hole or the shearing gear groove, and the equipment should be straight and straight. After that, check whether the electrical circuit and parts are damaged, whether the connection parts of the machine are reliable, and whether some of the transmissions are active.

  • What is the correct way to operate a can filling production line?

    The can filling production line, if it is a little careless in operation, there may be consequences that we cannot predict. Then, how should we operate it correctly? Here is the correct way to do it for you. 1. The work surface of the feeding material and the off-duty part of the cutter need to be kept on a horizontal scale, and the length of the work table should be determined according to the length of the material to be processed; 2. Before starting the can filling production line, we should pay attention to check and confirm whether the cutter has cracks, whether the bolts on the knife holder are loose, and try to turn the pulley by hand so that we can check whether the gear is It is consistent, and the cutter should be adjusted accordingly; 3. After the normal startup, the first thing to do is to check whether the operation of each part is normal. Generally speaking, the material can be cut only when the speed is normal; Fourth, when the can filling production line cuts short materials, our workers' hands should keep a distance from the cutter, so as to ensure the workers;

  • Under what conditions is a can beverage production line considered a good product?

    Under what conditions can a can beverage production line be considered a good product, and there is a standard for the difference between good and bad. Only when the conditions are met can it be regarded as a good product? The can beverage production line has the characteristics of novel style, small size, low voice, simple operation, advanced, high degree of automation and convenient operation. So there are so many types of can beverage production lines, what conditions need to be met to be considered excellent? In fact, it doesn't have any special standard at all, as long as the work efficiency is high, the speed is fast and so on, it can basically be said to be excellent. In a nutshell, their main features are: The production efficiency is high, and the wire feeding speed can be adjusted steplessly, and the wire feeding speed can be adjusted; Sophisticated materials, reasonable processing and heat treatment processes, high precision and strength of parts, and long service life are the basic standards for an excellent pop-top beverage production line. Others include high mechanical properties. Good, well-made, high-precision features.

Get in Touch

For any inquiries or feedback from customers, we will respond patiently and meticulously.

Industry Introduction
How to maintain Semi-automatic basket loading and unloading unit
To maintain a semi-automatic basket loading and unloading unit, you can follow these general steps:
    Regular cleaning: Keep the unit clean by removing any debris, dirt or dust that can accumulate on the unit.
    Lubrication: Apply lubrication to the moving parts of the unit to prevent wear and tear of the parts and to ensure smooth operation.
    Regular inspection: Inspect the unit regularly to detect any signs of wear, damage, or malfunction. Address any issues found immediately.
    Training: Ensure that the operators are properly trained on how to operate the unit and perform routine maintenance.
    Replacement of parts: Replace any worn or damaged parts as soon as possible to prevent further damage to the unit.
    Follow manufacturer's instructions: Follow the manufacturer's instructions for maintenance and operation of the unit.
    Safety measures: Follow all safety measures to ensure the safety of the operators and the unit.
By following these steps, you can ensure the longevity and efficient operation of your semi-automatic basket loading and unloading unit.
The advantages of Semi-automatic basket loading and unloading unit
Semi-automatic basket loading and unloading units offer several advantages, including:
    Increased efficiency: By automating the loading and unloading process, these units can reduce the time and effort required to handle baskets, leading to increased productivity and efficiency.
    Improved safety: By reducing the need for manual lifting and handling of heavy baskets, these units can improve worker safety and reduce the risk of workplace injuries.
    Consistency: Semi-automatic basket loading and unloading units can ensure that each basket is loaded and unloaded in a consistent manner, which can help maintain product quality and reduce errors.
    Cost savings: By reducing the need for manual labor, these units can help companies save on labor costs over time.
    Customizability: Many semi-automatic basket loading and unloading units can be customized to meet the specific needs of a particular operation, which can help improve performance and efficiency even further.
