XW36-6 High-speed filling and sealing combination machine

This machine is an exclusive development equipment of Newway on the basis of digestion and absorption of domestic and foreign (without steam) cans filling and sealing machine (sealing machine). According to the principle of atmospheric pressure filling, when empty tank enters the lifting tray through the pulley, the filling valve and empty tank are aligned, the empty tank is lifted and sealed, and the valve opening of filling valve is opened automatically. When the filling liquid level blockades the return pipe opening of the valve, the filling stops. The filling jar is sent to the sealing machine head by hook chain, and the lid is sent to the jar mouth by the cover feeder and the pressure head. When the supporting mechanism is lifted, the pressure head tightens the jar mouth. The sealing wheel is sealed first and then sealed. After the jar is sealed, the head of the capping mechanism is pushed out, and then the jar is transported out of the jar.

Functional characteristics

This machine adopts PLC, frequency converter and man- machine interface control system. It has control technology such as frequency conversion and speed regulation, automatic filling with cans, no cans and no filling. Through various sensors on the device, the accurate production speed and quantity can be displayed on the touch screen. The production speed can be set on the touch screen according to the user is requirements. The whole machine has various protections of main motor and other electrical appliances, such as overload, overvoltage, etc. At the same time, the corresponding faults will be automatically displayed on the touch screen to facilitate users to find out the causes of the faults. The main electrical components of this machine adopt internationally renowned brands, and can also be formulated according to customer requirements.
This machine is characterized by fast filling speed, consistency of the liquid level in the tank to the mouth height after filling, smooth operation, good sealing quality, elegant appearance,convenient use and maintenance, etc.

Main Technical Parameters

Model XW36-6
The number of sealing head 6
The number of filling head 36
Production capacity 30~400cans/min
Can Diameter Ф52.5~99mm
Can Height 39~160mm
Power 7.5kw
Weight 5000kg
Overall Dimensions 3600×2300×2100mm

XW36-6 High-speed filling and sealing combination machine

Marvelous Design Meets Rigorous Manufacturing


Years Of Experience

Zhejiang Newway Food Machinery Co., Ltd is Custom XW36-6 High-speed filling and sealing combination machine manufacturers and OEM XW36-6 High-speed filling and sealing combination machines suppliers, The company is mainly engaged in the design and manufacture of beverages, canning machines and sealing machines packed with tinplate, aluminium, plastic and paper materials, as well as related products. Undertake the whole production line of easy-to-open beverage (including steam, nonsteam), sauce filling and sealing production line, Babao porridge canning, food, fruit and vegetable canning production line, etc. The company fully uses CAD and CAM to design products. It is in a leading position in the field of filling and sealing equipment for canned food and beverage in China. The company specializes in the production of high-speed canning filling and sealing units and production lines, which make due contributions to the localization of similar imported equipment, reduce investment costs in the food and beverage industry, improve labor productivity of enterprises, and promote the rapid development and growth of the industry. The company relies on strong technical force and effective technical guarantee, flexible business philosophy and quality service, Favourable manufacturing technology, excellence in product quality and good reputation, to serve the vast number of new and old customers, and wholeheartedly welcomes friends from all walks of life to visit and patronize.
  • 2019

    Established in

  • 6,000m2

    plant area

  • 80


  • 10 +


Focus on the field of canned packaging and serve the domestic food industry.

Newway aims to be the partner of choice for its customers, providing more efficient food packaging solutions, high technology, expertise, flexibility and fast service.

  • Pragmatic

    People-oriented, customer-oriented, realistic, down-to-earth. In the market competition to seek the appropriate path of enterprise development and project development, to create value with products and services, to enhance the company's market competitiveness.

  • Innovation

    The society is developing day by day, and we are brave to stand on the tide and dare to be the first. Innovation is the soul of the enterprise, and only through innovation can we maintain the vitality of the enterprise.

  • Cooperation

    Standardize management, operate in good faith, follow the law and give back to the society. Establish a sound corporate governance structure, operation mechanism and business process, uphold the spirit of professionalism and dedication, and earnestly fulfill the social responsibility of a corporate citizen and win the affirmation of the market.

  • Our goal

    Our ambition is ambitious, our goal is clear and never-ending. Our goal is the spiritual driving force for our company to win competitiveness.

Company Certificate

Continuously strengthen the research and development and innovation of core technologies, keep improving, and ensure the excellent performance of each product with Favourable production equipment, strict quality management, and precise testing procedures.

Plant Equipment

As OEM XW36-6 High-speed filling and sealing combination machine manufacturers, the company has many of cutting-edge automated
production lines in China.

  • Factory

  • Factory

  • Factory

  • Factory

  • Factory

  • Factory

  • Factory

  • Factory

Industry Introduction

How to maintain High-speed filling and sealing combination machine
This High-speed filling and sealing combination machine is designed with the concept to optimize the filling, sealing and capping processes. This machine has a simple maintenance system that makes it easy to keep clean, maintain and repair. This fill-seal machine's modular design saves space while allowing flexibility in configuration according to your plastic bottles' size.
This machine is suitable for packaging soft and hard products, made of food, medicine, cosmetics and other sanitary materials.
The bottle filling and sealing machine’s major components include the thermoelectric vibrator, CNC servo motor and controller, air compressor, air dryer, water tank and other accessories. The most important part of this machine is the sealing needle. Therefore, it should be maintained regularly so that it can work stably
It is important to maintain a high-speed filling and sealing combination machine. If the machine is not maintained properly, it can affect the quality of the products produced by the company. It is recommended that these machines be inspected and serviced every six months by a trained technician

The advantages of High-speed filling and sealing combination machine
High-speed filling and sealing combination machine has a variety of advantages including superior performance, technological innovations and energy saving.
This machine is with high speed filling, sealing and capping characteristic. It can filling and sealing at the same time and so increases the efficiency.
Filling and sealing machine is a combination of filling jar, capping machine and automatic packaging machine. It can make the product with high efficiency and no pollution without any stopover during the whole process
Our High-speed filling and sealing combination machine are operating at a speed of 60-120 bottles per minute. The advantages are: 1) Compact design, light weight and easy to move 2) Save labor cost through multi-functions 3) Stable performance, high quality products 4) Easy operation
